Train Model: HCD 5000 New Energy Locomotive
Application: coal, metallurgy, petrochemicals, ports, railway logistics parks
Maximum traction force: 550 kN
Maximum speed: 60 km/h
Vehicle size: 18750*3200*4480 mm
Mleage: 150 km
RailMac Introduction
RailMac is a comprehensive supplier for manufacturing, maintaining, and leasing railway wagons, and offers a wide range of wagon spare parts for industries like steel, coal, chemicals, oil, energy, logistics, and local railway transportation. It provides services including R&D, manufacturing, reconfiguration, maintenance, leasing, and spare parts supply.
RailMac produces and repairs various wagons such as open, flat, self-unloading, hot metal, hopper, and special-purpose wagons. It also supplies spare parts like bogies, wheelsets, braking and coupling components. Annually, it manufactures over 1,000 wagons, repairs 3,000, leases 650-1,000, and sells more than 50,000 sets of spare parts.
RailMac aims to strengthen its customer base in steel, coal, chemical, local railway, and power industries, and expand into new metro vehicle construction. It offers on-site maintenance and transformation services for industrial and mining enterprises’ vehicles, and is applying for qualifications to produce military products in line with national policies. RailMac collaborates with research institutions and universities, engages in cross-shareholding, and explores international markets through the “Belt and Road” initiative.
Battery Trains
Battery Trains provides 4 battery-powered rail series—Battery Locomotive, Trolley Locomotive, Railway&Tunnel Construction, Sightseeing Train—all using advanced lithium-ion batteries. They replace diesel locomotives sustainably, fit existing infrastructure, and support greener, cost-effective rail; the firm leads eco-friendly transport.
Tourist Train
The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.
Traction System
CHSR’s CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary “two-in-one” core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.
Bogie and Braking System
CRRC Braking Systems Co., Ltd.’s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.
Track Body Components
RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.
Maintenance Equipment
RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.
Railway Components
CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water – saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.
RailMac
Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.
Find Type by RailMac bettery train Series
This is the list of all Railmac bettery train series for New Energy Locomotive, Battery Train, Trolley Locomotive, Railway&Tunnel Construction, Sightseeing Train.Click here to find RailMac bettery train by type
Battery Locomotive
| HCD-5000 New Energy Locomotive | 550 kN | |||||||
| HCD-3500 New Energy Locomotive | 310 kN | |||||||
| HCD-2500 New Energy Locomotive | 250 kN | |||||||
| HCD-1500 new energy locomotive | 173 kN | |||||||
| HCT-3000~5000 New Energy Electric Puller | 252-550 kN | |||||||
| 2.5T Battery Locomotive | 6.13 kN | |||||||
| 5T Battery Locomotive | 12.26 kN | |||||||
| 8T Battery Locomotive | 19.62-20.8 kN | |||||||
| 12T Battery Locomotive | 29.43-32 kN | |||||||
| 15T Battery Locomotive | 36.18-39 kN | |||||||
| 18T Battery Locomotive | 44.145-46.8 kN | |||||||
| 25T Battery Locomotive | 65 kN | |||||||
|
Trains Model Traction Force/kN |
0 | 100 | 200 | 300 | 400 | 500 | 600 | 700 |
| Battery Locomotive Series Catalogue | ||||||||
Series
Model
HCD-3500 New Energy Locomotive
Train Model: HCD 3500 New Energy Locomotive
Application: Coal, metallurgy, petrochemicals
Max Traction Force: 310 kN
Max Speed: 35 km/h
Vehicle Size: 14390*3285*4455 mm
Range: 150 km
HCD-2500 New Energy Locomotive
Train Model: HCD 2500 New Energy Locomotive
Application: coal, metallurgy, petrochemicals, ports, railway logistics parks
Max Traction Force: 250 kN
Max Speed: 35 km/h
Vehicle Size: 14000*3185*4255 mm
Range: 120 km
HCD-1500 New Energy Locomotive
Train Model: HCD-1500
Application: coal, metallurgy, petrochemicals, ports, railway logistics parks
Max Traction Force: 173 kN
Max Speed: 30 km/h
Vehicle Size: 7600*3000*4200 mm
Range: 60 150km
HCT-3000~5000 New Energy Electric Puller
Train Model: HCT-3000~5000
Application: automatic coal loaders and dump trucks
Max Traction Force: 252~550 kN
Max Speed: 8~35 km/h
Vehicle Size: 14275*3200*4340 mm
Range: 90 km
2.5T Battery Locomotive
Hourly System Traction: 2.55 kN
Max. Traction: 6.13 kN
Hourly System Speed: 4.54 km/h
Supply Voltage: 48 V
Capacity of Traction Battery: 308Ah or 330 Ah
Power of Electric Motor: 3.5kW*1
5T Battery Locomotive
Hourly System Traction: 7.06 kN
Max. Traction: 12.26kN
Hourly System Speed: 7km/h
Supply Voltage: 90V
Capacity of Traction Battery: 330 Ah or 385 Ah
Power of Electric Motor: 7.5 kW*2
8T Battery Locomotive
Hourly System Traction: 11.18~13.12 kN
Max. Traction: 19.62~20.8 kN
Hourly System Speed: 6.2~7.7 km/h
Supply Voltage: 110~144 V
Capacity of Traction Battery: 370 Ah or 440 Ah
Power of Electric Motor: 11 kw*2 or 15 kw*2
12T Battery Locomotive
Hourly System Traction: 15.96~22 kN
Max. Traction: 29.43~32 kN
Hourly System Speed: 8.7~14.03 km/h
Supply Voltage: 192~256 V
Capacity of Traction Battery: 560 Ah
Power of Electric Motor: 22 kW*2 or 30 kw*2
15T Battery Locomotive
Hourly System Traction: 18.93~20.92 kN
Max. Traction: 36.18~39 kN
Hourly System Speed: 9.6 km/h
Supply Voltage: 256 V
Capacity of Traction Battery: 620 Ah
Power of Electric Motor: 30 kW*2
18T Battery Locomotive
Hourly System Traction: 29.4~30.74 kN
Max. Traction: 44.145~46.8 kN
Hourly System Speed: 9.8 km/h
Supply Voltage: 208 V
Capacity of Traction Battery: 730 Ah
Power of Electric Motor: 40 kW*2 or 45 kw*2
25T Battery Locomotive
Hourly System Traction: 50.8 kN
Max. Traction: 65 kN
Hourly System Speed: 8.95 km/h
Supply Voltage: 288 V
Capacity of Traction Battery: 730 Ah
Power of Electric Motor: 65 kW*2
Trolley Locomotive
| 1.5T Trolley Locomotive | 3.68 kN | |||||||||
| 3T Trolley Locomotive | 7.38 kN | |||||||||
| 7T Trolley Locomotive | 17.2-18.2 kN | |||||||||
| 10T Trolley Locomotive | 24.5-26 kN | |||||||||
| 14T Trolley Locomotive | 34.3-36.4 kN | |||||||||
| 20T Trolley Locomotive | 49-52.9 kN | |||||||||
| 30T Trolley Locomotive | 72-78 kN | |||||||||
|
Trains Model Traction Force/kN |
0 | 10 | 20 | 30 | 40 | 50 | 60 | 70 | ||
1.5T Trolley Locomotive
Application: Mining
Hourly System Traction: 2.55~3.24 kN
Max. Traction: 3.68 kN
Hourly System Speed: 4.45~6.6 km/h
Supply Voltage: 100~250 V
Power of Electric Motor: 3.5 kW*1 or 6.5 kw*1
3T Trolley Locomotive
Application: Mining
Hourly System Traction: 7.5~10.6 kN
Max. Traction: 7.36 kN
Hourly System Speed: 7.5~10.6 km/h
Supply Voltage: 250~550 V
Power of Electric Motor: 12 kw*1 or 24 kw*1 or 6.5 kw*2
7T Trolley Locomotive
Application: Mining
Hourly System Traction: 13.05~15.16 kN
Max. Traction: 17.2~18.2 kN
Hourly System Speed: 9.8~11 km/h
Supply Voltage: 250~550 V
Power of Electric Motor: 21 kW*2 or 22 kw*2 or 24 kw*2
10T Trolley Locomotive
Application: Mining
Hourly System Traction: 13.05~19.13 kN
Max. Traction: 24.5~26 kN
Hourly System Speed: 9.8~11 km/h
Supply Voltage: 250~550 V
Power of Electric Motor: 21 kW*2 or 22 kw*2 or 24 kw*2 or 30 kw*2
14T Trolley Locomotive
Application: Mining
Hourly System Traction: 26.68~27.16 kN
Max. Traction: 34.3~36.4 kN
Hourly System Speed:11.2~12.87 km/h
Supply Voltage: 250~550 V
Power of Electric Motor: 45 kW*2 or 52 kW*2
20T Trolley Locomotive
Application: Mining
Hourly System Traction: 37.3~41.04 kN
Max. Traction: 49~52.9 kN
Hourly System Speed: 10.5~18.6 km/h
Supply Voltage: 550~750 V
Power of Electric Motor: 65 kW*2 or 75 kw*2 or 78 kw*2 or 85 kw*2 or 110 kw*2
30T Trolley Locomotive
Application: Mining
Hourly System Traction: 43~60 kN
Max. Traction: 72~78 kN
Hourly System Speed: 12.73~13.2 km/h
Supply Voltage: 550 V
Power of Electric Motor: 85 kW*2 or 110 kw*2
Railway&Tunnel Construction
| 115 kN | ||||||||
| 127 kN | ||||||||
| 142 kN | ||||||||
| 153 kN | ||||||||
| 165 kN | ||||||||
| 39 kN | ||||||||
| 50.96 kN | ||||||||
| 74 kN | ||||||||
| 81 kN | ||||||||
| 92 kN | ||||||||
|
Trains Model Traction Force/kN |
0 | 30 | 60 | 90 | 120 | 150 | 180 | 210 |
| Railway&Tunnel Construction Series Catalogue | ||||||||
Series
Model
45T Lead-acid Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 45 tons
Hourly System Traction: 89 kN
Max. Traction: 115 kN
Hourly Speed: 8.9 km/h
Rated Voltage: 540 V
50T Lead-acid Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 50 tons
Hourly System Traction: 98 kN
Max. Traction: 127 kN
Hourly Speed: 8.9 km/h
Rated Voltage: 540 V
55T Lead-acid Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 55 tons
Hourly System Traction: 120 kN
Max. Traction: 142 kN
Hourly Speed: 8.9 km/h
Rated Voltage: 540 V
60T Lead-acid Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 60 tons
Hourly System Traction: 120 kN
Max. Traction: 153 kN
Hourly Speed: 8.9 km/h
Rated Voltage: 540 V
65T Lead-acid Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 65 tons
Hourly System Traction: 130 kN
Max. Traction: 165 kN
Hourly Speed: 10 km/h
Rated Voltage: 540 V
15T Lithium Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 15 tons
Hourly System Traction: 20.92 kN
Max. Traction: 39 kN
Hourly Speed: 9.6 km/h
Rated Voltage: 320 V
20T Lithium Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 20 tons
Hourly System Traction: 39.23 kN
Max. Traction: 50.96 kN
Hourly Speed: 15 km/h
Rated Voltage: 537.6 V
25T Lithium Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 25 tons
Hourly System Traction: 65 kN
Max. Traction: 74 kN
Hourly Speed: 9 km/h
Rated Voltage: 537.6 V
30T Lithium Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 30 tons
Hourly System Traction: 71 kN
Max. Traction: 81 kN
Hourly Speed: 8.9 km/h
Rated Voltage: 537.6 V
35T Lithium Battery Locomotive
Application: subway and tunnel shield
Self-Weight: 35 tons
Hourly System Traction: 80 kN
Max. Traction: 92 kN
Hourly Speed: 10 km/h
Rated Voltage: 537.6 V
Sightseeing Train
Trains Model Capacity/people/train Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing Application: Sightseeing
P6 Series Monorail Sightseeing Train
31 People/train
P8 Series Monorail Sightseeing Train
45 people/train
P12 Series Monorail Sightseeing Train
69 people/train
P20 Series Monorail Sightseeing Train
110 people/train
600 Series Double-track Sightseeing Train
54 people/train
762 Series Double-track Sightseeing Train
120 people/train
1000 Series Double-track Sightseeing Train
120 people/train
1435 Series Double-track Sightseeing Train
138 people/train
CH4 Mountain Rack Track Train
44 people/train
CH6 Mountain Rack Track Train
36 people/train
CH12 Mountain Rack Track Train
72 people/train
Trackless Sightseeing Buses
72 people/train
0
20
40
60
80
100
120
140
Sightseeing Train Series Catalogue
Series
Model
P20 Series Monorail Sightseeing Train
Max Speed: 30 km/h
Min turning radius: 30 m
Max Climbing Ability: 10%
Dimension: 45m × 2.4m × 3.6m
P12 Series Monorail Sightseeing Train
Max Speed: 30 km/h
Min turning radius: 20 m
Max Climbing Ability: 10%
Dimension: 32m × 1.7m × 3.3m
P8 Series Monorail Sightseeing Train
Max Speed: 15 km/h
Min turning radius: 15 m
Max Climbing Ability: 10%
Dimension: 25m × 2m × 2.7m
P6 Series Monorail Sightseeing Train
Max Speed: 15 km/h
Min turning radius: 10 m
Max Climbing Ability: 10%
Dimension: 17m × 1.3m × 2.3m
1435 Series Double-track Sightseeing Train
Max Speed: 40 km/h
Min turning radius: 50 m
Max Climbing Ability: 5%
Dimension: 63.6m × 2.92m × 3.96m
1000 Series Double-track Sightseeing Train
Max Speed: 10 km/h
Min turning radius: 50 m
Max Climbing Ability: 5%
Dimension: 39.6m × 2.75m × 3.2m
762 Series Double-track Sightseeing Train
Max Speed: 10 km/h
Min turning radius: 30 m
Max Climbing Ability: 5%
Dimension: 39.6m × 2.4m × 3.4m
600 Series Double-track Sightseeing Train
Max Speed: 10 km/h
Min turning radius: 30 m
Max Climbing Ability: 5%
Dimension: 28m × 1.8m × 3.46m
CH12 Mountain Rack Track Train
Max Speed: 15 km/h
Min turning radius: 15 m
Max Climbing Ability: 35%
Dimension: 11(21/32)m×1.5m×2.2m
CH6 Mountain Rack Track Train
Max Speed: 15 km/h
Min turning radius: 10 m
Max Climbing Ability: 35%
Dimension: 15m × 1.5m × 2.2m
CH4 Mountain Rack Track Train
Max Speed: 15 km/h
Min turning radius: 10 m
Max Climbing Ability: 35%
Dimension: 12(24)m×1m×1.85m
Trackless Sightseeing Buses
Max Speed: 20 km/h
Min turning radius: 7 m
Max Climbing Ability: 7%
Dimension: 20.2m x 1.89m x 2.34m
Sales Team RailMac Manager-Mr.Leo RailMac Assistant-Ms.Cathy Generator-SinoGen EV System-EVMac Service Team Sales Manager-Mrs.Wendy Fu Sales Director-Mr.Jasper Lee Shipping Service
Contact EMAC Now!
